Semi-automatic Microplate Washer SAM208

来源：seebio.cn作者：西宝生物人气：-发表时间：2012-03-26 13:26:45【大中小】

Property:

a）Handling 8,12 filler heads and can be replaced;
b）Handling 8,12 imbibition heads and can be replaced;
c）Can put 24、48 and 96 holes standard ELISA Plate;
d）The wash time can arbitrarily set to satisfy the requirement.
e）Cleaning row number is 1-12 and require seqencing.
f）Soak time can arbitrarily set and the time is no limit;
g）It can satisfy all kinds of wash types;h）It can choose single filler and single imbibition function.
i）It can clean the filler and imbibition pipeline;j）It has multipoint imbibition function.

TECHNICAL SPECIFICATION:

1、electric mainframe：
a）Max Power Dissipation：30VA
b）run mode： continuously-running duty
2、Handling 8,12 filler heads and imbibition heads
3 The volumes of washing liquor bottle and liquid waste bottle are ≥2L.
4 Elisa plate standard applied:24 poles、48 poles、96 poles;
5 Working conditions:
a) Ambient temperature:10℃～40℃;
b)Relative humidity: 30％～75％;
c) 860hPa～1060hPa；Atmospheric pressure:860hPa～1060hPa；
d) Power requirement: alternating current 220V±22V;
e) Far away from the strong electromagnetic interference;
5 Volume of ejected liquid: 200μl-500μl and can continously adjust;
6 Residual quantity of cleanout fluid:≤1μl/hole;
7 Overall dimensions:length is 356mm,width is 291 mm and height is 91 mm.
